HGM6110/6120 AUTO START MODULE
HGM6110/6120 Auto Start Module ISSUE 2.0 2008-10-27 Page 4 of 24
1. SUMMARY
HGM6100 Series generator controller integrating digital, intelligent and network
techniques is used for automatic control system of diesel generator. It can carry
out functions including automatic start/stop, data measure and alarming. The
controller uses LCD display, optional Chinese and English display interface with
operation easy and reliable.
HGM6100 Series generator controller uses micro-processing technique which
can carry out precision measure, constant value adjustment, timing and threshold
setting and etc. of multi-parameters. It can be widely used in all types of generator
automatic control system for compact structure, advanced circuits, simple
connections and high reliability.
2. PERFORMANCE AND CHARACTERISTICS
HGM6100 controller has two types:◆
HGM6110: ASM (Automatic Start Module)
HGM6120: AMF (Automatic Mains Failure Module)
Using microprocessor as a core, graphics LCD with big screen and backlight, ◆
display between Chinese and English, key touch for operation.
Have a RS485 port, can used for communicat◆ e to PC.
Precision measure and display of◆
mains voltage
mains frequency (Hz)
mains current
generator voltage
generator current
generator frequency (Hz)
generator active power (kW)
generator inactive power (kVar)
generator apparent power (kVA)
generator power factor
generator starts count
generator hours count
generator cumulate electric energy (kWh)
generator temperature
generator pressure
generator fuel level
start battery voltage
Configurable single phase 2 wires or 2 phase 3 wires or 3 phase 4 wi◆ res AC
