SmartRG SR808ac - Hardware Description and Hardware Installation; Hardware Description; Front Panel

SR808ac Cable Modem User Manual
4
3 Hardware Description and Hardware Installation
3.1 Hardware Description
3.1.1 Front Panel
The following table describes the indicators on the front panel.
Indicator
Color
Status
Description
Power
Green
On
The device is powered on and the device
operates normally.
Off
The device is powered off.
D/S
Green
On
CM has locked D/S frequency
Blink
CM scan D/S frenquency
Off
Device is powered off.
U/S
Green
On
CM has locked U/S frequency
Blink
CM is range and scan U/S frequency
Off
Device is powered off or CM scan D/S
frequency.
Ethernet
1/2/3/4
Green
On
The Ethernet interface is connected.
Blink
Data is being transmitted through the
Ethernet interface.
Off
The Ethernet interface is disconnected.
WLAN
Green
On
WLAN is enabled.
Blink
Data is being transmitted through the
wireless interface.
Off
WLAN is disabled.
WPS
Green
On
Connection succeeds under Wi-Fi
Protected Setup.
Blink
Negotiation is in progress under Wi-Fi
Protected Setup.
Off
Wi-Fi Protected Setup is disabled.
USB
Green
On
The connection of USB flash disk has
established.
Off
No signal is detected.
