SR808ac Cable Modem User Manual
5
Indicator
Color
Status
Description
FXS1/2
Green
On
EMTA has registered with CMTS
Blink
EMTA send register request to CMTS
Off
EMTA is no detected
3.1.2 Rear Panel
The following table describes the interfaces or the buttons on the rear panel.
Interface
Description
Antenna
The antenna interface, for connecting the antennas.
Cable
RF cable port, for connecting HFC cable.
Reset
Press the button for at least 1 second and then release it. System
restores the factory default settings.
Eth 4~1
RJ-45 port, for connecting the router to a PC or another network
device.
USB 0~1
USB port, for connecting other USB storage devices.
Power
Power interface, for connecting the power adapter.
TEL1~2
RJ-11 port, for connecting the router to Phones.
Warning:
Do not press the Reset button unless you want to clear the current settings. The
Reset button is in a small circular hole on the rear panel. If you want to restore the
default settings, please press the Reset button gently for 1 second with a fine needle
inserted into the hole and then release the button. The system reboots and returns to
the factory defaults.
3.2 Hardware Installation
3.2.1 Connecting the Device
Please follow the steps below to connect the device.
Step1 Connect the Cable port of the CMRG with HFC cable.
Step2 Connect the Eth port of the CMRG to the network card of the PC via an
Ethernet cable.
