-11-
Use a 5mm/0.2'' Allen key for adjusting the height of the
seat as per the drawing on page number 3.
Pull the seat out as per the required height.
Use the 5mm/0.2” Allen key for locking the mechanism back.
A
B
C
After assembling the seat,
press down on the seat to
make sure it is well
reinforced.
C.
B.
A.
Seat Bolt Mount
Seat Installation
WARNING: In order to
prevent the seat from
becoming loose and a
possible loss of control, the
“MIN-IN” (minimum
insertion) mark A on the
seat post is placed below
the top of the seat tube B .
A
B
C
According to European standards,
do not insert the seat further than
the top mark (Illustration mark C ).
5mm / 0.2‘’
To Next Page
