5mm / 0.2‘’
5mm / 0.2‘’
4
-9-
5a
5b
A
B
4. Unfasten the 4 stem screws.
5a. Place the handlebar on the head tube.
5b. Reattach the stem and fasten the screws.
Handlebar and Stem Installation
