-7-
Fitting the
Assembly
No. No.
1
Description
Frame
2 Fork
3 Handlebar
4 Grips (x2)
5 Handlebar Stem
6 Seat
7 Seat Post
8 Clamp
9 Head Set Bearings
10
Right Pedal
20
Chain
21
Chain Cover
Balance Bike System
22
23
25
26
24
Bell
Reflectors
27
Coaster Brake
11 Left Pedal
12
Description
Wheel Retainer (x2)
Balance Bike System Bolts (x3)
13 Front Wheel Nut (x2)
15 Tyre (x2)
16 Tube (x2)
14 Front Wheel Assembly
17 Rear Wheel Assembly
18 Front brake disc
19 Hand Brake
Follow all the instructions completely and carefully.
Please read the entire manual through before starting
assembly or maintenance.
In case you are not confident with assembling this unit,
please refer to a local bike shop.
Parts Assembly List
Back Wheel Nut (x2)
WARNING: Keep small components away from children during the assembly
process.
NOTE: All of the directions (right, left, front, rear, etc.) provided in this
manual are as seen by the rider riding the bicycle.
Do not dispose of the carton or other packaging parts until the assembly of
the bicycle is complete. It can prevent accidentally discarding components
of the bicycle.
