Mechanical Specifications
PARAMETERS CONDITION VALUE UNITS
Weight Without batteries 2 Lbs
Housing Material
Injection
molded plastic
enclosure
Troubleshooting
The tool does not power up or
turns off when the Activate
button is pressed.
Replace batteries.
No tire pressure sensor data
is received.
Make sure the Activate Antenna is held
within 22” of the tire pressure sensor in
position before the Activate button is
momentarily selected and that tool is held
in that position for at least 3.5 to 5
seconds. Try to activate and receive tire
pressure sensor data from another tire
pressure sensor.
Setup menu button does not
work.
Be sure to press and hold the button for 2
seconds.
The tool does not receive a
sensor transmission after a
sensor has been activated.
Make sure the tool's antenna is held
within 6 inches of the sensor when
activating a sensor.
This process may need to be repeated up
to 3 times. If a sensor continues to not
respond, refer to the vehicle service
manual for further diagnostic or repair
information.
Wrong sensor initiated
(dual tire only).
When initiating a sensor in a dual tire
configuration the ID codes received
are the same for both the inner and
outer tires, the antenna of the tool
should be moved within 6 inches of
the tire pressure sensor (the antenna
should be held against the outer tire
when activating the inner tire on a
dual tire configuration)
21
