u Motor option
Nil
Without option
B
With lock
i Actuator cable type
*
1
Nil
Without cable
S
Standard cable
*
2
R
Robotic cable (Flexible cable)
*1 The standard cable should be used on fixed
parts. For using on moving parts, select the
robotic cable.
*2 Only available for the motor type “Step
motor”.
!1 I/O cable length [m]
*
1
, Communication plug
Nil
Without cable (Without communication plug connector
*
3
)
1
1.5
3
3
*
2
5
5
*
2
S
Straight type communication plug connector
*
3
T
T-branch type communication plug connector
*
3
*1 When “Without controller/driver” is selected
for controller/driver types, I/O cable cannot
be selected. When the I/O cable is required,
order it separately.
*2 When “Pulse input type” is selected for
controller/driver types, pulse input usable
only with differential. Only 1.5 m cables
usable with open collector.
*3 When “CC-Link direct input type” is selected
for controller/driver types, I/O cable is not
included. Only “Nil”, “S” or “T” can be
selected.
!2 Controller/Driver mounting
Nil
Screw mounting
D
DIN rail mounting
*
* DIN rail is not included. Order it separately.
o Actuator cable length [m]
Nil
Without cable
1
1.5
3
3
5
5
8
8
*
A
10
*
B
15
*
C
20
*
*
Produced upon receipt of order (Robotic cable only)
!0 Controller/Driver type
*
1
Nil
Without controller/driver
6N
LECP6/LECA6
(Step data input type)
NPN
6P
PNP
1N
LECP1
*
2
(Programless type)
NPN
1P
PNP
MJ
LECPMJ
*
2
*
3
(CC-Link direct input type)
—
AN
LECPA
*
2
*
4
(Pulse input type)
NPN
AP
PNP
*1 For details about controllers/driver and
compatible motors, refer to the compatible
controllers/driver below.
*2 Only available for the motor type “Step motor”.
*3 Not applicable to CE.
*4 When pulse signals are open collector, order
the current limit resistor (LEC-PA-R-l)
separately.
Compatible Controllers/Driver
Type
Step data
input type
Step data
input type
CC-Link
direct
input type
Programless type Pulse input type
Series
LECP6 LECA6 LECPMJ LECP1 LECPA
Features
Value (Step data) input
Standard controller
CC-Link direct input
Capable of setting up operation (step data)
without using a PC or teaching box
Operation by pulse signals
Compatible motor
Step motor
(Servo/24 VDC)
Servo motor
(24 VDC)
Step motor
(Servo/24 VDC)
Maximum number of step data 64 points 64 points 14 points —
Power supply voltage 24 VDC
* Copper and zinc materials are used for the motors, cables, controllers/drivers.
*
Specifications and dimensions for the
25A-series are the same as standard products.
Motor mounting position:
Right side parallel
Motor mounting position:
In-line
154
Electric Actuator/Slider Type
Ball Screw Drive
Series 25A-LEFS
