How to Order
157
Series 25A-LEY
LEY16, 25, 32, 40
Confirm that the combination of the controller/driver and the actuator is correct.
The actuator and controller/driver are sold as a package.
<Check the following before use.>
q
Check the actuator label for model number (after "25A-"). This matches the controller/driver.
w Check Parallel I/O configuration matches (NPN or PNP)
Electric Actuator/Rod Type
25A-LEY
16 100
B C 11 6N
* Refer to the applicable stroke table.
*
When “With lock/motor cover” is selected for the top mounting
and right/left side parallel types, the motor body will stick out of
the end of the body for size 16 with strokes 30 or less. Check
for interference with workpieces before selecting a model.
* Refer to the operation manual for using the products. Please download it via our website, http://www.smcworld.com
S
q w e r t y u i o !0 !1 !2 !3
* Applicable stroke table
* Consult with SMC for non-standard strokes as they are produced as special orders.
q Size
r Lead [mm] t Stroke [mm]
y Motor option
u Rod end thread
w
Motor mounting position
e Motor type
[CE-compliant products]
qEMC compliance was tested by
combining the electric actuator
LEY series and the controller LEC
series.
The EMC depends on the configu-
ration of the customer’s control
panel and the relationship with
other electrical equipment and wir-
ing. Therefore conformity to the
EMC directive cannot be certified
for SMC components incorporated
into the customer’s equipment un-
der actual operating conditions.
As a result it is necessary for the
customer to verify conformity to
the EMC directive for the machinery
and equipment as a whole.
wFor the servo motor (24 VDC)
specification, EMC compliance
was tested by installing a noise
filter set (LEC-NFA). Refer to the
WEB catalog for the noise filter
set. Refer to the LECA Operation
Manual for installation.
[UL-compliant products]
When conformity to UL is required,
the electric actuator and controller/
driver should be used with a UL1310
Class 2 power supply.
Caution
Standard
Symbol
Type
Size
Compatible
controllers/driver
LEY16 LEY25
LEY32/40
Nil
Step motor
(Servo/24 VDC)
LECP6
LECP1
LECPA
LECPMJ
A
Servo motor
(24 VDC)
LECA6
Stroke
[mm]
Model
30 50 100 150 200 250 300 350 400 450 500
Manufacturable
stroke range
[mm]
LEY16
10 to 300
LEY25
15 to 400
LEY32/40
20 to 500
30
30
to to
500
500
Nil
Female rod end
M
Male rod end
(1 rod end nut is included.)
C
With motor cover
W
With lock/motor cover
Symbol
LEY16 LEY25 LEY32/40
A
10 12 16
B
5 6 8
C
2.5 3 4
Nil
Top mounting
R
Right side parallel
L
Left side parallel
D
In-line
16
25
32
40
Solid state auto switches should be ordered separately.
For details about auto switches, refer to page 164.
Applicable auto switches
D-M9N(V)-900, D-M9P(V)-900, D-M9B(V)-900
D-M9NW(V)-900, D-M9PW(V)-900, D-M9BW(V)-900
Mounting Bracket Part No. for Series 25A-
*1 When ordering foot brackets, order 2 pieces per actuator.
*2 Parts belonging to each bracket are as follows.
Foot, Flange: Body mounting bolt, Double clevis: Clevis pin, Type C retaining ring for axis, Body mounting bolt
Applicable size
Foot
*
1
Flange Double clevis
16
25-LEY-L016 25-LEY-F016 25-LEY-D016
25
25-LEY-L025 25-LEY-F025 25-LEY-D025
32, 40
25-LEY-L032 25-LEY-F032 25-LEY-D032
Surface
treatment
RAYDENT
®
RAYDENT
®
Coating
(Size 16: Electroless nickel plating)
Step Motor
(Servo/24 VDC)
Servo Motor
(24 VDC)
RoHS
q w
®
25A-P-B-P157-web-CS3e.indd 157 15.2.13 2:06:16 PM
