Parameter Setting
The EX600 parameters can be configured for the system, each unit, and each channel.
Parameters can be changed by CoE object dictionary (page 89), or the Web server (page 114).
The following tables show settable parameters for the SI unit, I/O units, and ITV module.
■System parameters
No.
Parameter
Definition
Item
Content
Default
setting
4
Power supply for
control and input
voltage monitor
Monitor 24V_C
(US1)
Generated error when
control and input
power supply voltage
goes under approx.
19 VDC.
Enable
Generates an error.

Disable
Does not generate an error.
5
Power supply for
output voltage
monitor
Monitor 24V_D
(US2)
Generated error when
output power supply
voltage goes under
approx. 19 VDC.
Enable
Generates an error.
Disable
Does not generate an error.

6
Hold/Clear
priority setting
Switch the setting of
the output during
communication error
or communication
idling to follow the
setting of the SI unit
or the parameters.
Via switch
Setting by SI unit switch
becomes valid. (page 20)
OFF/Hold can be set output of
all.

Via software
Parameter settings by the CoE
object dictionary, or the web
server become valid.
OFF/Hold/Forced ON can be set
per channel.
7
Byte order
Switch the byte
sequence with which
the analogue values
are transferred to the
controller.
LSB-MSB
The data format of all analogue
units and ITV modules is
assumed to be LSB-MSB.

MSB-LSB
The data format of all analogue
units and ITV modules is
assumed to be MSB-LSB.
