-21-
EX※※-OMR1012
•IP address setting switch (5 of the settings1 is ON)
Settings1 Settings2
1 2 3 1 2 3 4 5 6 7 8
IP address Subnet mask
OFF OFF OFF ON OFF OFF OFF OFF OFF OFF OFF 136.129.0.1
: : : : : : : : : : : :
OFF OFF OFF OFF ON ON ON ON ON ON ON 136.129.0.254
255.255.248.0
ON OFF OFF ON OFF OFF OFF OFF OFF OFF OFF 136.129.1.1
: : : : : : : : : : : :
ON OFF OFF OFF ON ON ON ON ON ON ON 136.129.1.254
255.255.248.0
: : : : : : : : : : : :
: : : : : : : : : : : :
: : : : : : : : : : : :
:
OFF ON ON ON OFF OFF OFF OFF OFF OFF OFF 136.129.6.1
: : : : : : : : : : : :
OFF ON ON OFF ON ON ON ON ON ON ON 136.129.6.254
255.255.248.0
ON ON ON ON OFF OFF OFF OFF OFF OFF OFF 136.129.7.1
: : : : : : : : : : : :
ON ON ON OFF ON ON ON ON ON ON ON 136.129.7.254
255.255.248.0
ON/OFF ON/OFF ON/OFF ON ON ON ON ON ON ON ON DHCP mode
1
OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF Remote Control mode
2
1: The mode to obtain IP address from DHCP server. Obtained IP address etc. is lost when the power supply is cut.
2: The mode to respond to the commands below of BOOTP/DHCP Server provided by Rockwell Automation.
Enable DHCP: IP address etc. can be obtained from BOOTP/DHCP Server.
If the power is supplied again in this state, information including IP address is obtained again.
Disable DHCP: IP address etc. cannot be obtained from BOOTP/DHCP Server.
If the power is supplied again with this condition, previous setting can be held.
