-20-
EX※※-OMR1012
(2) 5 of the settings1 is ON
IP address range: 136.129.0.1 to 136.129.7.254.
Subnet mask: 255.255.248.0
Settings 1 Settings 2
1 1
2 2
3
IP address byte 3 setting
3
4 Hold/Clear setting 4
5
ON
5
6 6
7
Reserved
7
8 Diagnostics setting 8
•IP address byte 4 setting
•DHCP mode setting
•HOLD/CLEAR switch: Sets the output status when the fieldbus has a communication error or is in idling
state.
Settings1
4
Content
OFF Output is OFF. (default setting)
ON Holds the output.
: This switch can be enabled and disabled by parameter.
•Switch for diagnosis: Allocates the diagnostic data to the input data.
Settings1
8
Mode Content
Diagnostic size set
for the input
OFF 0 Input data only (default setting) 0 byte
ON 1 Input data + System diagnosis + Unit diagnosis 4 bytes
●Precautions for handling
•Handle the switch with care. Excessive force can break the switch.
•6, 7 of the Settings1 switch are not used.
