EX※※-OMR1012
•IP address setting switch (5 of the settings1 is OFF)
Settings1 Settings2
8 1 2 3 4 5 6 7 8
IP address Subnet mask
OFF ON OFF OFF OFF OFF OFF OFF OFF 192.168.0.1
OFF OFF ON OFF OFF OFF OFF OFF OFF 192.168.0.2
: : : : : : : : : :
OFF ON OFF ON ON ON ON ON ON 192.168.0.253
OFF OFF ON ON ON ON ON ON ON 192.168.0.254
255.255.255.0
ON ON OFF OFF OFF OFF OFF OFF OFF 192.168.1.1
ON OFF ON OFF OFF OFF OFF OFF OFF 192.168.1.2
: : : : : : : : : :
ON ON OFF ON ON ON ON ON ON 192.168.1.253
ON OFF ON ON ON ON ON ON ON 192.168.1.254
255.255.255.0
ON/OFF ON ON ON ON ON ON ON ON DHCP mode
1
ON/OFF OFF OFF OFF OFF OFF OFF OFF OFF Remote Control mode
2
1: The mode to obtain IP address from DHCP server. Obtained IP address etc. is lost when the power supply is cut.
2: The mode to respond to the commands below of BOOTP/DHCP Server provided by Rockwell Automation.
Enable DHCP: IP address etc. can be obtained from BOOTP/DHCP Server.
If the power is supplied again in this state, information including IP address is obtained again.
Disable DHCP: IP address etc. cannot be obtained from BOOTP/DHCP Server.
If the power is supplied again with this condition, previous setting can be held.
