•Analogue input unit parameters
Parameter
setting
No. Parameter Definition Item Content
Default
setting
By
E.O.
By
W.S.
Enable Generates an error.
1
The power
supply short
circuit
detection for
the input
device
Generates error
per unit when the
short circuit of the
power supply for
the input device is
detected.
Disable
Does not generate an
error.
-10..10 V
-5..5 V
-20..20 mA
0..10 V
0..5 V
1..5 V
0..20 mA
2
Analogue
input range
Set the analogue
input device range
per channel.
4..20 mA
Selects the analogue
input range.
-10..10 V
Offset binary Offset binary.
Sign &
Magnitude
Signed binary.
3
Analogue
data format
Sets analogue data
type which is output
to PLC per unit.
2s complement 2’s complement.
None None
2AVG 2 value average
4AVG 4 value average
4
Analogue
average filter
Sets analogue
filtering time per
channel.
Sampling interval is
approx. 2 sec.
8AVG 8 value average
Enable Generates an error.
5
Over range
detection
Generates error
per unit when the
input value
exceeds 0.5% of
full span.
Disable
Does not generate an
error.
Enable Generates an error.
6
Under range
detection
Generates error
per unit when the
input value falls
below 0.5% of full
span.
Disable
Does not generate an
error.
Enable Generates an error.
1
7
User setting
value upper
limit error
Generates error
per unit when the
input value
exceeds the set
value.
Disable
Does not generate an
error.
Enable Generates an error.
1
8
User setting
value lower
limit error
Generates error per
channel when the
input value falls
below the set value.
Disable
Does not generate an
error.
1: Set value shall be set per analogue input range within settable range in the table below.
When the analogue input range is changed, check the set value and change it to an appropriate value.
