•Analogue output unit parameters (2)
Parameter
setting
No. Parameter Definition Item Content
Default
setting
By
E.O.
By
W.S.
Enable
Output will be user idle
value.

7
Output setting
for
communication
idling
 
Set output per
channel during
communication
idling.
Disable
Output will be held last
state.
○
○ ○
1: Set value shall be set per analogue input range within settable range in the table below.
When the analogue input range is changed, check the set value and change it to an appropriate value.
2: This function is valid only when “Hold/Clear priority” of the system parameter is set to “Via software“.
3: Some PLC does not support an idle mode.
Table. Settable range for user set upper or lower limit and Fault Value
User set output value
Settable range
Range
Lower limit Upper limit
Settable range during
communication error or
idling
0..10 V 0.00 to +10.45 V +0.05 to +10.50 V 0.00 to +10.50 V
0..5 V 0.00 to +5.22 V +0.03 to +5.25 V 0.00 to +5.25 V
1..5 V +0.75 to +5.22 V +0.78 to +5.25 V +0.75 to +5.25 V
0..20 mA 0.00 to +20.90 mA +0.10 to +21.00 mA 0.00 to +21.00 mA
4..20 mA +3.00 to +20.90 mA +3.10 to +21.00 mA +3.00 to +21.00 mA
Table. User set values (PLC)
Range
Settable value by PLC
(Offset Binary
Signed Magnitude
2’s Complement)
Expected value
0..10 V
0 to 1050
0.00 to +10.50 V
0..5 V
0 to 525
0.00 to +5.25 V
1..5 V
75 to 525
+0.75 to +5.25 V
0..20 mA
0 to 2100
0.00 to +21.00 mA
4..20 mA
300 to 2100
+3.00 to +21.00 mA
: If the data format is scaled data format, set the data as follows, regardless of the range setting.
•PLC set value: 0 to 32767 → Converted value +0 to +32767
•PLC set value: 32768 to 65535 → Converted value -0 to -32767
