Details of Communication Format
HECR 4-8
4.10 Communication Format and Examples of Answers from
Thermo-con
Examples of commands and answers from the thermo-con (unit unspecified)
Command
code
ASCII
Command
Unit
specified
Host requirement
(ASCII code)
Answer from thermo-con
(ASCII code)
Content
31
Reading setting temperature
No
05 31 33 31 0D
02 31 32 35 30 30 03 3F 38 0D
Answer
“25.0 deg.C.”
31
Temperature setting
(without writing FRAM)
No
02 31 32 35 30 30 03 3F 38 0D
06 0D
Set at
25.0 deg.C
32
Reading internal sensor
No
05 32 33 32 0D
02 32 32 35 30 32 03 3F 3B 0D
Answer
“25.02 deg.C”
33
Reading external sensor
No
05 33 33 33 0D
02 33 33 30 30 32 03 3F 38 0D
Answer
“30.02 deg.C”
34
Reading alarm status
No
05 34 33 34 0D
02 34 30 38 30 03 3C 3C 0D
Answer
“ERR11”
36
Reading offset
No
05 36 33 36 0D
02 36 2D 31 35 32 03 3F 3B 0D
Answer
“-1.52 deg.C”
Offset setting
(without writing FRAM)
No
02 36 30 31 35 30 03 3F3C 0D
06 0D
Set at
+1.50 deg.C
37
Temperature setting
(with writing FRAM)
No
02 37 32 35 30 30 03 3F3E 0D
06 0D
Set at
25.0 deg.C
38
Offset setting
(with writing FRAM)
No
02 38 30 31 35 30 03 3F3E 0D
06 0D
Set at
+1.50 deg.C
Examples of commands and answers from the thermo-con (unit specified)
Command
code
ASCII
Command
Unit
specified
Host requirement
(ASCII code)
Answer from thermo-con
(ASCII code)
Content
31
Reading setting temperature
2
01 32 05 31 36 38 0D
01 32 02 31 32 35 30 30 03 32
3C 0D
Answer
“25.0 deg.C”
31
Temperature setting
(without writing FRAM)
2
01 32 02 31 32 35 30 30 03 32
3C 0D
06 32 OD
Set at
25.0 deg.C
32
Reading internal sensor
2
01 32 05 32 36 39 0D
01 32 02 32 32 35 30 32 03 32
3F 0D
Answer
“25.02 deg.C”
33
Reading external sensor
2
01 32 05 33 36 3A 0D
01 32 02 33 33 30 30 32 03 32
3C 0D
Answer
“30.02 deg.C”
34
Reading alarm status
2
01 32 05 34 36 3B 0D
01 32 02 34 30 38 30 03 30 30
0D
Answer
“ERR11”
36
Reading offset
2
01 32 05 36 36 3D 0D
01 32 02 36 2D 31 35 32 03 32
3F 0D
Answer
“-1.52 deg.C”
Offset setting
(without writing FRAM)
2
01 32 02 36 30 31 35 30 03 33
30 0D
06 32 0D
Set at
+1.50 deg.C
37
Temperature setting
(with writing FRAM)
F
01 3F 02 37 32 35 30 30 03 33
3F 0D
06 3F 0D
Set at
25.0 deg.C
38
Offset setting
(with writing FRAM)
F
01 3F 02 38 30 31 35 30 03 33
3F 0D
06 3F 0D
Set at +1.50
deg.C
