HEC-OM-O018-A
Chapter 5 Operation
5.1 Operation of Controller
5-12
<2> Communication speed setting
Function
Sets the communication speed.
The set value can be scrolled with the ▲ and ▼ keys.
1.2 ⇔ 2.4 ⇔ 4.8 ⇔ 9.6 ⇔ 19.2
Selectable setting 2.4 ~ 38.4 (2400 bps ~ 38400 bps)
PV
SV
Initial setting 9.6 (9600 bps)
<3> Communication address setting
Function
Sets the communication address of the product.
Set with [▲] or [▼] key
Setting range 1 to 99 addresses
PV
SV
Initial setting 1 address
<4> Response delay time setting
Function
Sets the response delay time.
Set with [▲] or [▼] key
Setting range 0 to 250 ms
PV
SV
Initial value 0 ms
<5> Communication-mode setting
Function
Sets the communication-mode setting.
Select with [▲] or [▼] key
Selectable
setting
or
: Readout only, : Readout and writing
PV
SV
Initial value
To Next Page
