SMC Networks ITV SEN DUX02357 Series User Manual

IN19856
- 24 - Rev 2
18.4. Scaling the engineering units
The engineering units are scaled to use integer math and as a result require a multiplier to be used
when sending the pressure set point of the desired engineering unit type. The multiplier used
depends on what type of ITV unit is being communicated with and what type of engineering unit is
selected. Please see the tables below for a full description with an example following –
ITV Unit Type – 0.1 MPa
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
Multiplier
100000
10000
10000
1000
100
See Section 18.1
ITV Unit Type – 0.5 MPa
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
Multiplier
100000
10000
10000
100
100
See Section 18.1
ITV Unit Type – 0.9 MPa
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
Multiplier
10000
1000
1000
100
10
See Section 18.1
ITV Unit Type – -80 kPa (vacuum unit)
Engineering
Units
MPa
Kg/cm^2
BAR
PSI
kPa
Counts
Multiplier
100000
10000
10000
1000
100
See Section 18.1
