SMC Networks ZSE30 Series User Manual

2-Color Display
High-Precision Digital Pressure Switch
The settings of the master sensor can be copied to the slave sensors.
P
Reduced setting efforts
P
Reduced chance of set-value input error
Settings can beSettings can be copiedcopied to up to to up to 1010 slave sensors at once. slave sensors at once.Settings can be copied to up to 10 slave sensors at once.
33-step setting-step setting3-step setting
PushPushPush
Finish setting
3
PushPushPush
1
2
Adjust to set-value 
with buttons.
Added vacuum range.
P Rated pressure range: 0.0 to –101.0 kPa
2 added outputs
P NPN or PNP open collector 2 outputs
P NPN or PNP open collector 1 output + Analog output
(1 to 5 V or 4 to 20 mA)
–101 kPa
0
Master
Unit 1Slave → Unit 2 Unit 10
CopCopyyCopy
Expanded pressure range
for positive-pressure type
to the vacuum range.
P Rated pressure range: –0.100 to 1.000 MPa
1 MPa
0
–0.1 MPa
(–100 kPa)
CAT.ES100-70B
Series ZSE30A
(
F
)
/ISE30A
RoHS
compliant
