-23-
No.PS※※-OMV1001
[F 1] Setting of OUT1 Page 25
Item
Description
Default setting
Output mode
Select hysteresis mode or window comparator mode.
Hysteresis mode
Reversed output
Select reversed output.
Normal output
Pressure setting
Set the ON or OFF point of the switch output
X576: 250 Pa
X577: 0.500 kPa
X578: 1.00 kPa
X579: 2.50 kPa
X580: 5.00 kPa
Hysteresis
Set the hysteresis to prevent chattering.
X576: 25 Pa
X577: 0.050 kPa
X578: 0.10 kPa
X579: 0.25 kPa
X580: 0.50 kPa
Display colour
Select the display colour.
ON: Green
OFF: Red
[F 2] Setting of OUT2 Page 28
Same setting as for [F 1] OUT1.
The display colour is linked to the setting of OUT1, and can not be set for OUT2.
Other parameter settings
Item
Page
Default setting
[F 3] Response time
page 29
Digital filter:1 s
Delay time: 4 ms
[F 4] Display resolution
page 32
Depends on the specification of the
special product
[F 5] Auto-preset function
page 33
Manual
[F 6] Fine adjustment of display value
page 35
0%
[F 7] Power saving mode
page 36
OFF
[F 8] Security code
page 37
OFF
[F 9] Setting of low-cut function
Page 38
OFF
[F90] Setting of all functions
page 39
OFF
[F97] Copy function
page 41
OFF
[F98] Check of output
page 43
Normal
[F99] Reset to the default setting
page 45
OFF
