Instructions for the installer
31
2. INSTALLATION OF THE APPLIANCE
This unit is equipped with a type Y fire protection, and may be set
against walls that are higher than the hob.
2.1 Electrical connection
Make sure that the power line voltage matches the specifications
indicated on the rating plate located inside the storage compartment.
This rating plate must never be removed.
On the power line, install an omnipolar cut-off device with contact cut-off
distance greater than or equal to 3 mm, located in an easily accessible
position near the unit.
The appliance is fitted with a terminal board at the rear for electrical
connections (see following diagram). To access, remove the rear cover.
