Burner and nozzle characteristics tables
The nozzles not provided are available at Authorised Service Centres.
1 Natural Gas G20 AUX SR R UR2
Rated heating capacity (kW)
1.05 1.8 3.0 4.2
Nozzle diameter (1/100 mm)
72 97 115 75 + 135
Pre-chamber (printed on nozzle)
(X) (Z) (Y) (H1)+(H3)
Reduced capacity (W)
400 500 800 1900
2 Natural Gas G25 AUX SR R UR2
Rated heating capacity (kW)
1.05 1.8 3.0 4.2
Nozzle diameter (1/100 mm)
72 94 121 75 + 145
Pre-chamber (printed on nozzle)
(F1) (Y) (F2) (H1)+(H3)
Reduced capacity (W)
400 500 800 1900
3 Natural Gas G25 AUX SR R UR2
Rated heating capacity (kW)
1.05 1.8 3.0 4.1
Nozzle diameter (1/100 mm)
77 100 134 80 + 145
Pre-chamber (printed on nozzle)
(F1) (Y) (F3) (Y)+(H3)
Reduced capacity (W)
400 500 800 1900
4 LPG G30/31 AUX SR R UR2
Rated heating capacity (kW)
1.05 1.8 3.0 4.2
Nozzle diameter (1/100 mm)
50 65 85 46 + 91
Reduced capacity (W)
400 500 800 1900
Rated capacity G30 (g/h)
76 131 218 305
Rated capacity G31 (g/h)
75 129 214 300
5 LPG G30/31 AUX SR R UR2
Rated heating capacity (kW)
1.05 1.8 3.0 4.2
Nozzle diameter (1/100 mm)
43 58 70 43 + 70
Pre-chamber (printed on nozzle)
(H2) (M) (S) (S1)+(H2)
Reduced capacity (W)
400 500 800 1900
Rated capacity G30 (g/h)
76 131 218 305
Rated capacity G31 (g/h)
75 129 214 300
6 City Gas G110 AUX SR R UR2
Rated heating capacity (kW)
1.05 1.8 2.8 4.0
Nozzle diameter (1/100 mm)
145 185 260 150 + 320
Pre-chamber (printed on nozzle)
(8) (2) (3) -
Reduced capacity (W)
400 500 800 1400
7 City Gas G120 AUX SR R UR2
Rated heating capacity (kW)
1.05 1.8 3.0 4.0
Nozzle diameter (1/100 mm)
135 175 240 130 + 290
Pre-chamber (printed on nozzle)
(8) (1) (3) -
Reduced capacity (W)
400 500 800 1400
