Instructions for the installer
40
3.2 Burner and nozzle characteristics table (60 cm model)
Burner
Rated
heating
capacity
(kW)
LIQUID GAS – G30/G31 30/37 mbar
Nozzle
diameter
1/100 mm
By-pass
mm
1/100
Reduced
capacity
(W)
Capacity
g/h G30
Capacity
g/h G31
Auxiliary 1.0 50 30 350 73 71
Semi-rapid 1.8 65 33 450 131 129
Rapid (3) 3.0 85 45 800 218 214
Rapid (5) 2.5 79 45 800 182 179
Triple crown 3.2 91 65 1500 233 229
Oven 3.2 87 50 900 233 229
Grill 2.9 87 // // 211 207
Burner
Rated
heating
capacity
(kW)
CITY GAS – G110 8 mbar
Nozzle
diameter 1/100 mm
Reduced capacity
(W)
Auxiliary 1.0 145 350
Semi-rapid 1.8 185 450
Rapid (3) 3.0 260 800
Rapid (5) 2.5 230 800
Triple crown 3.5 290 1200
Oven 3.2 270 900
Grill 2.9 270 //
The values for city gas refer to appliances in category III 1a2H3+.
Burner
Rated
heating
capacity
(kW)
NATURAL GAS – G20 20 mbar
Nozzle
diameter 1/100 mm
Reduced capacity
(W)
Auxiliary 1.0 72 350
Semi-rapid 1.8 97 450
Rapid (3) 3.0 115 800
Rapid (5) 2.5 108 800
Triple crown 3.5 133 1500
Oven 3.2 130 900
Grill 2.9 130 //
