Smeg CC92 - Page 2

The gas bayonet tting must terminate to the left hand side of the cooker when viewed from the rear and must be within 100mm from the
edge of left hand side, it must not be directly behind the appliance. The bayonet tting must be no higher than 700mm and no lower than
600mm from the oor.
The gas bayonet tting must terminate to the right hand side of the cooker when viewed from the rear and must be within 100mm from the
edge of right hand side, it must not be directly behind the appliance. The bayonet tting must be no higher than 700mm and no lower
than 600mm from the oor.
Please ensure your electricity connection is no more than 1metre away from where the appliance will be situated.
Electrical
connection
point
A 15mm BSP
socket elbow
(bayonet tting)
Gas
supply
point
VIEW FROM REAR
600mm to 700mm
Electrical
connection
point
100mm
Gas
supply
point
Electrical
connection
point
MODELS: CC92/SUK91/SUK92/CPF9GP/CPF9IP/A1/A2/A3/A4/A5
MODELS: TR4110/ TR93/ TR90*/SYD4110/SY93
The gas bayonet tting must terminate to the right hand side of the cooker when viewed from the rear and must be within 100mm from
the edge of right hand side, it must not be directly behind the appliance. The bayonet tting must be no higher than 700mm and no
lower than 600mm from the oor.
A 15mm BSP
socket elbow
(bayonet tting)
Gas
supply
point
VIEW FROM REAR
600mm to 700mm
100mm
Gas
supply
point
Electrical
connection
point
MODELS: TR103
VIEW FROM REAR
Gas
supply
point
Electrical
connection
point
Gas
supply
point
A 15mm BSP
socket elbow
(bayonet tting)
600mm to 700mm
Electrical
connection
point
100mm
*The appliance must be secured to the wall using the brackets or chain provided
ELECTRIC COOKERS
Cookers delivery and connection guide page 2/3
