Instructions for the installer
7
Overall dimensions: location of gas and electrical connection points (all
measures in mm).
30 CM
HOB
70 CM
HOB
A 60 120
B 90 90
C 30 30
D 90 70
2.2 Clearance above and around domestic appliances
Extract from AS5601
