Instructions for the user
66
12.3 Removing the door
12.3.1 With moveable levers
Open the door fully and lift levers A away
from the two hinges.
Grasp the door on both sides with both
hands, lift it forming an angle of around
45° and remove it.
If the hinges have not unlocked, repeat
the operation, raising levers A as
described above and keeping the door
slightly raised.
To reassemble the door, put the hinges in
the relevant slots in the oven, making
sure that grooved sections C are resting
completely in the slots. Lower the door
and, once it is in position, disengage
levers A.
