Burner and nozzle characteristics table
1 Natural Gas G20 AUX SR UR-3c
Rated heating capacity (kW) 1.05 1.8 3.5
Nozzle diameter (1/100 mm) 72 97 134
Pre-chamber (printed on nozzle) (X) (Z) (F3)
Reduced flow rate (W) 400 500 1600
2 Natural Gas G20 AUX SR UR-3c
Rated heating capacity (kW) 1.05 1.8 3.5
Nozzle diameter (1/100 mm) 72 94 128
Pre-chamber (printed on nozzle) (X) (Z) (S)
Reduced flow rate (W) 400 500 1600
3 Natural Gas G25 AUX SR UR-3c
Rated heating capacity (kW) 1.05 1.8 3.5
Nozzle diameter (1/100 mm) 72 94 138
Pre-chamber (printed on nozzle) (F1) (Y) (F3)
Reduced flow rate (W) 400 500 1600
4 Natural Gas G25.1 AUX SR UR-3c
Rated heating capacity (kW) 1.05 1.8 3.5
Nozzle diameter (1/100 mm) 77 100 145
Pre-chamber (printed on nozzle) (F1) (Y) (F3)
Reduced flow rate (W) 400 500 1600
5 Natural Gas G25 AUX SR UR-3c
Rated heating capacity (kW) 1.05 1.8 3.5
Nozzle diameter (1/100 mm) 77 100 145
Pre-chamber (printed on nozzle) (F1) (Y) (F3)
Reduced flow rate (W) 400 500 1600
6 Natural Gas G2.350 AUX SR UR-3c
Rated heating capacity (kW) 1.0 1.8 3.6
Nozzle diameter (1/100 mm) 94 120 200
Pre-chamber (printed on nozzle) (Y) (Y) (H3)
Reduced flow rate (W) 400 500 1600
