Instructions for the user
29
4. DESCRIPTION OF THE CONTROLS
Auxiliary Burner (AUX)
Rapid Burner (R)
Double crown Burner (UR2)
KNOB DESCRIPTION
To light the flame, press the knob and, at the same time,
turn it anticlockwise to the maximum flame symbol .
To adjust the flame, turn the knob to the zone between the
maximum ( ) and minimum ( ) settings.
To turn off the burner, turn the knob to the position.
ARRANGEMENT OF BURNERS AND DESCRIPTION OF SYMBOLS
Front Auxiliary burner UR2 External crown
Back Rapid burner UR2 Internal crown
