Instructions for the Installer
6
2 INSTALLING THE APPLIANCE
It is the law that all gas appliances are installed by authorised persons. Clearance aroun
the cooker must comply with the requirements of AS5601.
2.1 Electrical connection
Check that the voltage and size of the power supply line are as specified on the nameplate inside the
storage compartment.
This nameplate must never be removed.
If a permanent connection to the electrical mains is used, the appliance's power supply line must be
fitted with an omnipolar breaking device with contact breaking gap of at least 3 mm located in an
easily accessible position close to the appliance itself.
For operation on 220-240 V
∼
: use an H05RR-F or H05V2V2-F type
three-core cable (3 x 2.5 mm
2
).
For operation on 380-415 V 2N
∼
: use an H05RR-F or H05V2V2-F
type four-core cable (4 x 1.5 mm
2
).
For operation on 380-415 V 3N
∼
: use an H05RR-F or H05V2V2-F
type five-core cable (5 x 1.5 mm
2
).
The cable end to be connected to the appliance must be
provided with an earth wire (yellow-green) at least 20 mm
longer.
The manufacturer declines all responsibility for damage to persons or things caused by non-
observance of the above prescriptions or by interference with any part of the appliance.
