Instructions for the installer
21
Burner
Rated
heating
capacity
(kW)
LPG – G30/G31 28/37 mbar
Nozzle
diameter
1/100 mm
Reduced
capacity
(W)
Capacity
g/h G30
Capacity
g/h G31
Auxiliary (1) 1.0 48 400 73 71
Semi-rapid (2) 1.7 62 450 124 121
Medium rapid (3) 2.6 76 650 189 186
Large Rapid (4) 3.1 85 750 225 221
Ultra-rapid (5) 3.3 87 1400 240 236
Double crown
Internal (6) 1.0 48 400 73 71
External (6) 3.9 92 1200 284 279
(*) By-pass value for appliances without valves.
9.3 Adjustment for natural gas
The cooker hob is preset for natural gas G25 (2ELL) at a pressure of 20 mbar. To
reset the appliance for operation with this type of gas, carry out the same steps as
described in “9.2 Adjustment for LPG”, but select the nozzles and adjust the primary
air for natural gas as indicated in the table below and in "9.5 Primary air adjustment”.
After the adjustments have been carried out, restore the seals with sealing wax or
equivalent material.
Burner
Rated
heating
capacity
(kW)
Natural gas – G25 20 mbar
Nozzle diameter
1/100 mm
Reduced capacity
(W)
Auxiliary (1) 1.1 82 400
Semi-rapid (2) 1.7 98 450
Medium rapid (3) 2.6 126 650
Large Rapid (4) 3.0 140 750
Ultra-rapid (5) 3.3 145 1400
Double crown
Internal (6) 1.1 82 400
External (6) 3.9 155 1200
