USER INTERFACE MODULE (UIM)/ TOUCH SCREEN DISPLAY
Tank Temperature 71°F
Operating Setpoint 184°F
Status: Ignition
HELPDISABLE
A. O. Smith XP
MENU
OFF
GAS
O
N
LCD
Touch
Screen Display
Status Icons
Main Menu Help MenuEnable / Disable Button
Figure 75. User Interface Module (UIM)/ Touch Screen Display
