Power on the device
and start therapy
Slower
Cancel
Faster
Progressing to target pressure.
Cancel
Progressing to target pressure.
Faster
Target pressure achieved.
Press the button
to start/pause
the therapy
3
Select the prescribed
negative pressure level
using the + or – buttons
MenummHg
Set target pressure
80
60 100
22hr
MenummHg
Set target pressure
100
80 125
22hr
MenummHg
Set target pressure
125
100 150
22hr
2
4
When the pump
is working correctly
the OK light
will illuminate
Switch On
the pump
1
RENASYS
◊
EDGE Quick reference guide 2
