6 126-99-01 Rev. C SPIDER2 Limb Positioner Instructions for Use
To Clean SPIDER2
1. Remove all single use components and accessories. Discard single use components.
Refer to cleaning and sterilization instructions for accessories: 79-99-04 Cleaning and
Sterilization Instructions.
2. Wipe entire SPIDER2 with mild detergent / disinfectant, taking care to avoid fluid entry
into Switch Drape or Foot Pedal Receptacles.
3. Wipe battery with mild detergent / disinfectant.
4. Dry SPIDER2 with a cloth or allow to air dry.
5. DO NOT immerse any portion of SPIDER2 in liquid. If moisture enters the equipment it
can cause corrosion, and damage electrical and/or mechanical components.
6. DO NOT autoclave SPIDER2.
7. DO NOT use ethylene oxide to sterilize SPIDER2.
Storage
1. Turn OFF and DEPRESSURIZE SPIDER2 by disconnecting the Foot Pedal and/or Switch
Drape and pressing the Power Switch to the DEPRESSURIZE Position for 1 second (Figure
2). The Power Switch will then return to the OFF/STORAGE Position.
2. Always depressurize and then turn off the SPIDER2 when not in use. Failure to do so will
reduce the life expectancy of the device.
Maintenance
Only trained individuals should perform maintenance on SPIDER2. Contact Smith &
Nephew to determine which maintenance can be performed on site.
SPIDER2 Specifications*
*Specifications are approximate and may vary from unit to unit or as a result of power
supply fluctuations
Model REF 72203299 SPIDER2
Size (fully extended)
Length: 1495 mm Width: 180 mm
Height: 200 mm
Weight 30 lbs [13.6 kg] (with battery installed)
Approval
CSA International
CAN/CSA-C22.2 No.601.1-M90
UL 60601-1
IEC 60601-1
Equipment type Type B Applied Part
Power Supply Internally Powered 24V 15A
Battery Type NiCd 24V 1.8Ah
Battery Model REF 72203301 SPIDER2 Battery Pack
Enclosure Protection IPX1 Drip-proof equipment
Environmental Conditions Operation Storage & Transportation
Temperature 10°C - 40°C -40°C - 70°C
Relative Humidity 30% - 75% 10% - 100%
Atmospheric Pressure 70kPa - 106kPa 50kPa - 106kPa
Disposal
EU: Not for general waste
Contact Smith & Nephew for appropriate methods of
disposal.
SPIDER2 Battery Charger Specification
Approval
Intertek
CAN/CSA Std C22.2 No. 60950-1
UL 60950-1
IEC 60950-1
Power supply 100-240 VAC, 50-60 Hz, Max 0.9 A
Ordering Information
SPIDER2 Accessories*
REF Description
72203301 SPIDER2 Battery Pack
7210570 Piggy Back
7210749 90° Connector
7210577 Traction Accessory
7210571 Shoulder Connection Bar
7210576 Lateral Shoulder Connection Bar
7210572 Elbow Connection Bar
72200660 Wrist Arthroscopy Accessory
72202932 Ankle Arthroscopy Accessory
72203235 SPIDER Leg Accessory (Left)
72203236 SPIDER Leg Accessory (Right)
72203239 3D SPIDER Connector
* SPIDER2 is packaged with:
(1) SPIDER2
(1) SPIDER2 Battery Pack
(1) SPIDER2 Battery Charger
(3) Power Cords (Type A - NEMA 1-15, Type C - CEE 7/16 Europlug, Type G - BS 1363).
Contact Smith & Nephew for additional power cords, if required.
Stabilization Kits
72203833 SPIDER2 Shoulder Stabilization Kit
7210573 Shoulder Stabilization Kit
7210574 Elbow Stabilization Kit
72201550 Small Wrist Stabilization Kit
72201551 Medium Wrist Stabilization Kit
72201552 Large Wrist Stabilization Kit
72202931 Ankle Stabilization Kit
72203238 Leg Stabilization Kit
72203300 Switch Drape
Warranty
This product has a standard 12-month parts and labor warranty against manufacturing
defects.
For Further Information
If further information on this product is needed, contact Smith & Nephew Customer Service
at +1 800 343 5717 in the U.S., or an authorized representative.
