Smittybilt XRC8 User Manual

Installation Manual
Step 7: Re-install gasket on cover. (If it was removed) (Fig I)
Step 8: Re-install gear cover back onto winch using the previously removed bolts. (Fig J)
Step 9: Once all bolts are tighten check operation of new clutch lever by turning between engaged
mode and free spool mode. You should feel the “click” and feel it lock into position. Installation
is now complete.

Smittybilt XRC8 Specifications

General

Brand	Smittybilt
Model	XRC8
Category	Winches
Language	English
