10
TRUBLESHOTING / MAINTENANCE
ERROR
PROBABLE CAUSE
SOLUTION
The welding machine does not deliver
current. Completely inoperative.
Switch set to 0
Set it to 1.
Main fuse burnt.
Replace them.
Plug not correctly inserted in the
power socket.
Insert the plug.
The welding machine does not deliver
current but the motor fan is running.
the power plug is not wired properly.
Please refer to the troubleshoting
tip section located at our web site
(www.800ABCWELD.com) for infor-
mation on wiring the 220V plug if
needed.
Thermostat open: yellow lamp lit.
Wait approximately 5/6 min.
See protection devices.
WELDER MAINTENANCE
Electrical shock can result when contacting live
electrode or internal components
Electrical shock can result from absence of
grounding lug.
Welding machine must be connected to
power source in accordance with applicable
electrical codes.
Do not touch electrode or internal compo-
nents without protection.
Disconnect power before servicing.
Do not remove the grounding lug in any elec-
trical plug.
Electrical shock can cause injury.
In case of maintenance inside the welder, make sure the
switch F is in “O” position and that the power supply
cable is disconnected from the main.
Periodically, also clean the inside of the welder and
remove any metal dust using compressed air.
HOW TO PROCEED AFTER MAKING REPAIRS
After making repairs, always ensure the wires are fully
insulated between the primary side and the secondary
side of the machine. Avoid the wires coming into contact
with moving parts or parts that heat up during operation.
Fit all the clamps back as on the original machine so as to
avoid any contact between the primary and secondary in
case of accidental lead breakage or disconnection.
Also t the screws back on with the toothed washers as
on the original machine.
