Briggs & Stratton Vanguard EFI
12 volt, 20 amp alternator, Battery: 340
cca
Electrical System
CHASSIS
Capacity: 12 gallons (45,4 L) total -
Models with two fuel tanks
Fuel Tank
Capacity: 6 gallons (22,7 L) total -
Models with one fuel tank
Tire Size: 24 X 12.00 - 12Rear Wheels
Inflation Pressure: 15 psi (1,03 bar)
Tire Size: 13 X 6.50 - 6Front Wheels
Inflation Pressure: 25 psi (1,72 bar) -
Models with air filled tires
Inflation Pressure: N/A (Flat Free Tire)
- Models with flat free tires
TRANSMISSIONS
Hydro-Gear®Make
1015-1024L (LH)Model (Units with 61" Mower Decks)
1015-1024R (RH)
1015-1057L (LH)Model (Units with 72" Mower Decks)
1015-1057R (RH)
ZT5400 TransaxlesType
SAE 20W-50 motor oilHydraulic Fluid
Forward: 0-10 MPH (0-16,09 km/h)Speeds @ 3400 rpm
Reverse: 0-5 MPH (0-8,05 km/h)
DIMENSIONS
Models with 61" Mower Deck
80" (203 cm)Overall Length
76" (193 cm)Overall Width (with discharge chute
down)
63" (160 cm)Overall Width (with discharge chute
up)
57" (145 cm)Overall Height (with Roll Bar down)
70" (178 cm)Overall Height (with Roll Bar up)
1190 lbs (540 kg)Weight (approximate)
Models with 72" Mower Deck
83.5" (213 cm)Overall Length
87.5" (223 cm)Overall Width (with discharge chute
down)
74" (188 cm)Overall Width (with discharge chute
up)
58" (147 cm)Overall Height (with Roll Bar down)
71" (180 cm)Overall Height (with Roll Bar up)
1439 lbs (653 kg)Weight (approximate)
Warranty
If your unit is equipped with a dual function hour meter that
displays both engine hours and PTO hours, the warranty is
based on the engine hours as displayed by the hour meter.
Warranty Statement
BRIGGS & STRATTON WARRANTY POLICY (January 2014)
LIMITED WARRANTY
Briggs & Stratton warrants that, during the warranty period
specified below, it will repair or replace, free of charge, any part
that is defective in material or workmanship or both.
Transportation charges on product submitted for repair or
replacement under this warranty must be borne by purchaser.
This warranty is effective for and is subject to the time periods
and conditions stated below. For warranty service, find the
nearest Authorized Service Dealer in our dealer locator map at
snapperpro.com
.The purchaser must contact the Authorized
Service Dealer, and then make the product available to the
Authorized Service Dealer for inspection and testing.
There is no other express warranty. Implied warranties,
including those of merchantability and fitness for a
particular purpose, are limited to the warranty period listed
below, or to the extent permitted by law . Liability for
incidental or consequential damages are excluded to the
extent exclusion is permitted by law. Some states or countries
do not allow limitations on how long an implied warranty lasts,
and some states or countries do not allow the exclusion or
limitation of incidental or consequential damages, so the above
limitation and exclusion may not apply to you. This warranty
gives you specific legal rights and you may also have other
rights which vary from state to state or country to country.**
WARRANTY PERIOD
Rental Warranty PeriodStandard Warranty
Period
Covered Parts
90 days4 years (48 months) or
500 hours, whichever
occurs first.
Unlimited hours during
the first 2 years (24
months)
Riding mowers - except
as noted below +
90 days2 years (24 months)
unlimited hours
Walk mowers - except as
noted below +
(over 30 inches of cutting
width)
90 days90 days+Hydro Drive Belt,
Gearbox Drive Belt,
Tires, Brake Pads,
Hoses, Battery, Blades
90 days1 year (12 months) or
100 hours, whichever
occurs first
+Mower Deck Drive Belt
(Conventional Single Belt
Deck Drive Systems)
90 days3 years (36 months) or
300 hours, whichever
occurs first.
(Parts and labor in year
one; parts only in years
two and three.)
+Mower Deck Drive Belts
(Two Belt Deck Drive
Systems)
90 days1 year+Attachments
51
