Operation
CheckTire Pressures
Tire pressure should be checked periodically, and
maintained at the levels shown in the chart. Note that these
pressures may differ slightly from the "Max Inflation"
stamped on the side-wall of the tires. The pressures shown
provide proper traction, improve cut quality, and extend tire
life.
Tire Pressure
Front 25 psi (1,72 bar)
Rear 15 psi (1,03 bar)
Figure3. CheckingTirePressure
SeatAdjustment
SeeFigure 4. The seatcan be adjusted forward and
backward. Move the lever towards the left, position the seat
as desired, and releasethe lever to lock the seat into
position.
Seat Adjustment (Suspension Seat)
See Figure5. In addition to the forward and backward seat
adjustment, models equippedwith a suspension seat can be
adjusted for lumbar support, suspension and back angle.
Forwardand BackwardAdjustment:
Move the forward / backwardseat adjustment lever (A,
Figure5) away from the seat, position the seat as desired,
and releasethe leverto lock the seat into position.
LumbarAdjustment:
Turnthe lumbar adjustment knob (B) until the desired
amount of lumbar is achieved.
BackAngleAdjustment:
Turnthe backangle adjustment knob (C) until the desired
amount of back angle is achieved.
SuspensionAdjustment:
Turnthe suspension adjustment knob (D) until the display
scale has a readingthat matchesthe weight of the operator.
Figure4. SeatAdjustment
A. Seat Adjustment Lever
Figure5. Suspension SeatAdjustment
A. Forward / Backward SeatAdjustment Lever
B. Lumbar Adjustment Knob
C. BackAngle Adjustment Knob
D. Suspension Adjustment Knob
17
