17
Fig. 7
ASSEMBLY
TO INSTALL BATTERY PACK (See Figure 7)
• Lift and hold up the battery door (1).
• Align the battery (2) with the mower’s battery port.
• Make sure the battery release button (3) snaps in place and that battery is
fully seated and secure in the mower before beginning operation.
• Insert the safety key (4). If the machine is not going to be used immediately,
do not insert the safety key.
• Close the door.
TO REMOVE BATTERY PACK (See Figure 7)
• Release the bail lever to stop the mower.
• Open the battery door. Remove the safety key.
• Press the battery release button (3) on the mower. This will cause the
battery to raise out of the tool slightly.
• Remove battery from the mower.
(3)
(1)
(2)
(4)
