12
Ignition Switch
The ignition switch starts and stops the engine; it
has three positions:
OFF Stops the engine and shuts o the
electrical system.
RUN Allows the engine to run and powers the
electrical system.
START Cranks the engine for starting.
NOTE: Never leave the ignition switch in the RUN posi-
tion with the engine stopped–this drains the battery.
PTO Switch
The PTO (Power Take-O) switch engages and
disengages the mower blade clutch. To engage the PTO,
pull UP on the switch. Push DOWN to disengage. Note
that the operator must be seated rmly in the rider seat for
the PTO to function.
Transmission Release Levers
The transmission release levers deactivate the
transmissions so that the unit can be pushed by hand
(see Pushing the Unit by Hand).
Seat Adjustment
The seat can be adjusted forward and backward
(see Seat Adjustment).
Fuel Tank Cap
To remove the cap, turn counterclockwise.
Deck Lift Pedal, Cutting Height
Adjustment Pin and Deck Lift
Lock Lever
Adjusts the mower cutting height. See Cutting Height
Adjustment.
Hour Meter (optional)
The hour meter measures the number of hours the
key has been in the RUN position.
NOTE: The hour meter will register the passage of time
when the engine is running. The hour meter has a self-
contained power source so the total hours are always
visible.
