Snapper G Series Parts Manual

15
FRAME, CLUTCH, BRAKE & STEERING COMPONENTS
ITEM PART NO. DESCRIPTION
1 7-3345 FRAME, Tractor (1 piece)
2 1-4451 TIE, Wire
3 2-7936 ROD END (2)
4 9-0482 NUT, 3/8-24 Hex Jam (2)
5 9-0163 SCREW, 3/8-24 x 1-1/4” Hex Cap (2)
6 2-8420 LINK, Drag
7 2-4180 SPACER (2)
8 9-0613 NUT, 3/8-16 Hex Flange Lock
9 5-3568 ASSEMBLY, Sector Gear
(Includes 4-1267 Weldment & item 10)
10 1-2706 BEARING, Sector Gear (2)
11 3-1036 WASHER, 3/4” Thrust
12 9-0583 NUT, 1/4-20 Hex Flange Lock (6)
13 2-2381 BOLT, 1/2-13 x 2” Shoulder (2)
14 9-0975 NUT, 1/2-13 Hex Center Lock Gr. A
15 7-2636 BRACE, Sector Gear
16 1-2080 TIE, Cable 7”
17 9-0585 NUT, 5/16-18 Hex Flange Lock, Gr. 5 (4)
18 2-2743 PEDAL, Clutch Brake
19 1-2661 PAD, Pedal
20 9-1299 NUT, 3/8-16 Hex Nyloc
21 9-0122 WASHER, 3/8 Bright Zinc, Flat (2)
22 2-4381 SPRING, Brake
23 2-8037 SWIVEL, Inline Brake
24 9-1593 PIN, 3/8 x 1-7/32” Cotter (Self-
Locking) (5)
25 9-1575 NUT, 5/16-18 Hex Center Lock (4)
26 9-2031 NUT, 5/16-24 Hex Jam Lock
27 9-1300 WASHER, .44” I.D. Flat
28 5-8339 WELDMENT, Brake Arm
29 -- ARM, Speed Control
(Component of transaxle, page 14)
30 7-2369 ROD, Brake
31 9-0188 WASHER, 5/16” Flat
32 4-6782 SPRING
33 3-2070 WASHER, .406 I.D. Flat (2)
34 7-3607 SWIVEL, Brake Link
35 9-2058 NUT, 5/16-24 Hex Top Lock
36 7-2626 ASSEMBLY, Clutch/Brake Cable
37 5-2431 ASSEMBLY, Foot Shaft Pivot
(Includes item 38)
38 1-3864 FITTING, Lube, 3/16
39 9-0509 WASHER, 1/2” Internal Tooth Lock
ITEM PART NO. DESCRIPTION
40 9-0619 NUT, 1/2-13 Hex Flange Lock
41 1-5992 WASHER, 5/8” Flat (2)
42 2-3645 PIN, 3/16 x 1-1/2” Clevis
43 2-2742 BEARING, Flange
44 4-1236 WELDMENT, Clutch Brake Arm
45 4-1244 LATCH, Park Brake
46 9-0361 SCREW, 5/16-18 x 5/8” Self-Tap (3)
47 9-0803 BOLT, 1/4-20 x 5/8” Carriage (6)
48 9-1240 SCREW, #10-32 x 5/8” Self-Tap. (2)
49 1-1016 BUSHING, 1/2” Nylon (2)
50 9-1587 WASHER, 1/2” Flat (2)
51 1-4341 RING, 1/2” External Retaining (3)
52 9-1001 SCREW, 5/16-18 x 5/8” Truss (5)
53 9-1514 WASHER, 3/8 Yellow Zinc Flat (3)
54 7-2298 BRACKET, Pivot Mounting
55 2-3649 WASHER, 5/16” Nylon (2)
56 7-2403 KNOB, Clutch/Brake (5/16-18)
57 9-1302 NUT, 3/8-16 Hex, Grade B or 5
58 3-3557 ARM, Idler (Traction Drive)
59 9-0376 NUT, #10-32 Hex Nyloc (2)
60 2-3355 SWITCH, DPDT NC/NO
61 2-4383 SPRING, Traction Drive
62 3-4410 BRACKET, Rear Lift/PTO Lever
63 3-4347 LINK, Lift (33” Deck)
-- 3-4850 LINK, Lift (38” Deck)
64 3-4384 SPACER (2)
65 3-3520 BRACKET, Deck Hang Pivot
66 4-1249 WELDMENT, Rear Lift Arm (33” Deck)
-- 4-2597 WELDMENT, Rear Lift Arm (38” Deck)
67 9-1000 SCREW, 5/16-18 x 7/8” Truss
Head (Torx) (2)
68 3-4377 PLATE, Lift Sector (2)
69 3-4326 EXTENSION, Idler Arm
70 9-1501 SCREW, 3/8-16 x 2-1/2” Cap Grade 5
71 2-3954 PULLEY, Flat Idler, 3.47” O.D.
72 3-3556 GUIDE, Pulley (2)
73 9-1320 WASHER, 3/8” Split Lock
74 4-7072 BRACKET, Frame Brace
75 9-0731 BOLT, 5/16-18 x 5/8” Short Neck
Carriage, Grade 5 (2)
76 9-0368 SCREW, 5/16-18 x 3/4” Self-Tap (2)
77 2-4159 COTTER PIN, 1/16 x 1-7/32” Self Lock
78 7-2598 BRACKET, Mounting Brace
79 9-1097 BOLT, 5/16-18 x 3/4” Carriage, (2)
80 9-1497 SCREW, 3/8-16 x 1-1/2” Cap, Grade 5
81 2-4344 PULLEY, Idler V 3.30
82 9-1585 NUT, 3/8-16 Hex Center Lock
83 2-7139 LINKAGE
84 7-3608 ROD, Shift Linkage
85 9-1066 SCREW, 5/16-18 x 1-1/2” Cap
86 2-9973 SPACER
87 9-1575 NUT, 5/16-18 Hex Center Lock
88 2-4604 BOLT, 12-13 x 3-7/8” Shoulder
MANUAL No. 06448
