Thank you for purchasing this quality-built Rear Engine
Rider. We’re pleased that you’ve placed your confidence in
the brand. When operated and maintained according to the
manuals, your product will provide many years of dependable
service.
The manuals contain safety information to make you aware of
the hazards and risks associated with the unit and how to
avoid them. This Rear Engine Rider was designed to be used
as described in operator’s manual and is not intended for any
other purpose. It is important that you read and understand
the instructions thoroughly before attempting to start or oper-
ate this equipment. Save these original instructions for future
reference.
This product requires final assembly before use. Refer to the
setup guide for instructions on final assembly procedures.
Follow the instructions completely.
Products Covered by This Manual
The following products are covered by this manual:
2691347-00, 2691348-00, 2691354-00
Manual Contents:
Operator Safety .................................................................8
Features and Controls .................................................. 13
Safety Interlock Systems Checks .................................. 14
Operation ......................................................................... 14
Maintenance .................................................................... 18
Troubleshooting .............................................................. 23
Specifications .................................................................. 24
The images in this document are representative, and are
meant to complement the instructional text they accompany.
Your unit may vary from the images displayed. LEFT and
RIGHT are as seen from the operator’s position.
Operator Safety
Safety Alert Symbol and Signal Words
The safety alert symbol indicates a potential personal
injury hazard. A signal word (DANGER, WARNING, or
CAUTION) is used with the alert symbol to designate a
degree or level of hazard seriousness. A safety symbol may
be used to represent the type of hazard. The signal word
NOTICE is used to address practices not related to personal
injury.
DANGER indicates a hazard which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazard which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazard which, if not avoided, could
result in minor or moderate injury.
NOTICE indicates an action that could result in damage to
the product.
Rear Engine Rider Hazard Symbols
General Operator Safety Warning
Symbol Meaning Symbol Meaning
Safety informa-
tion about haz-
ards that can
result in personal
injury.
Read and under-
stand the opera-
tor’s manual
before operating
or servicing the
unit.
Thrown objects
hazard.
Amputation
hazard - rotating
blade. Keep feet
away.
Amputation haz-
ard - do not touch
moving parts.
Amputation
hazard - rotat-
ing blade. Keep
hands away.
Keep bystand-
ers and children
away.
Toxic fume haz-
ard.
Fire hazard. Explosion hazard.
Battery explosion
hazard.
Shock hazard.
Hot surface haz-
ard.
Explosion hazard.
Shock hazard. Kickback hazard.
Eye protection
recommended.
Ear protection
recommended for
extended use.
