35
Specifications
Specifications
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Power Ratings
The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of
Automotive Engineers) code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance
has been obtained and corrected in accordance with SAE J1995 (Revision 2002-05). Torque values are derived
at 3060 RPM; horsepower values are derived at 3600 RPM. Actual gross engine power will be lower and is
affected by, among other things, ambient operating conditions and engine-to-engine variability. Given both the
wide array of products on which engines are placed and the variety of environmental issues applicable to
operating the equipment, the gas engine will not develop the rated gross power when used in a given piece of
power equipment (actual "on-site" or net power). This difference is due to a variety of factors including, but not
limited to, accessories (air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application limitations,
ambient operating conditions (temperature, humidity, altitude), and engine-to-engine variability. Due to
manufacturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this
Series engine.
ENGINE:
Briggs & Stratton
Make Briggs & Stratton
Model Snow Max
Gross Torque 9 @ 3060 rpm
Displacement 12.5 Cu. in (205 cc)
Oil Capacity 18-20 oz. (0,54-0,59 L)
CHASSIS:
Wheels
Tire Size: 13 x 5
Inflation Pressure: 20 psi (1,37 bar)
Spout Rotation 200 Degrees
Impeller 10” (30cm) 4 Blade Ribbon Flighted Steel
Auger Opening Height 24” (61 cm)
Drive System Friction Disc, 6 Forward Speeds, 2
Reverse
DIMENSIONS
Effective Clearing Width
24” (61cm)
Length
54” (137cm)
Height
42.5” (108cm)
Weight SMI - 180 lbs. (81.64 kg)
SNP - 177 lbs. (80.28 kg)
