Snapper XD Series User Manual

43
PARTS LIST
Item No. Part No. Description QTY
46 ----- SWITCH, SIGNAL 1
47 ----- PCB 1
48 ----- SCREW 1
12A 770379 KIT, TOP COVER ASSEMBLY,NA 1
60 ----- SCREW 3
61 ----- COVER, TOP 1
62 ----- SCREEN, DUST 1
13A 770240 KIT, PCB, FOR STARTING 1
14A 770241 KIT, INPUT TUBE ASSEMBLY 1
92 ----- SPRING 1
93 ----- TUBE,INPUT 1
15A 770242 KIT, OIL TANK ASSEMBLY 1
90 ----- O-RING, SEAL 1
91 ----- TANK, OIL 1
16A 770243 KIT, OIL TANK CAP ASSEMBLY 1
63 ----- STRAP, OIL CAP 1
64 ----- O-RING, SEAL 1
65 ----- ELEMENT, FILTER 1
66 ----- CAP, OIL TANK 1
17A 770244 KIT, LEFT HOUSING ASSEMBLY, NA 1
67 ----- BUTTON 1
68 ----- HOUSING, LEFT 1
69 ----- NUT 2
70 ----- SCREW 5
71 ----- SCREW 2
72 ----- BRACKET, STABALIZER 1
18A 770245 KIT, MOTOR COVER ASSEMBLY, NA 1
73 ----- SCREW 3
74 ----- SCREW 2
75 ----- COVER, MOTOR 1
19A 770246 KIT, MOTOR ASSEMBLY, NA 1
76 ----- MOTOR 1
77 ----- CHANNEL, AIR OUTLET 1
78 ----- HOUSING, GEAR BOX 1
79 ----- GEAR 1
82 ----- BRACKET, FIXED MOUNTING 1
83 ----- SCREW 1
84 ----- SCREW 3
85 ----- COVER, GEAR BOX 1
Not for Reproduction

Snapper XD Series Specifications

General

Chain Brake	Yes
Engine Displacement	42 cc
Power Source	Gasoline
Bar Length	18 inches
Chain Pitch	0.325 in
Chain Gauge	0.050 inches
