Snapper XD Series User Manual

44
PARTS LIST
Item No. Part No. Description QTY
86 ----- SHAFT 1
88 ----- BEARING 1
20A 770247 KIT, OIL VALVE ASSEMBLY 1
94 ----- ASSEMBLY, OIL VALVE 1
95 ----- SCREW 2
21A 770248 KIT, FRONT HAND GUARD ASSEMBLY 1
96 ----- SPRING, TORSION 1
97 ----- SCREW 2
98 ----- BUSHING 1
99 ----- HANDGUARD,FRONT 1
100 ----- BUSHING 1
22A 770249 KIT, BUMPER SPIKE ASSEMBLY 1
101 ----- BRACKET, BUMPER SPIKED 1
102 ----- SCREW 2
23A 770250 KIT, CHAIN BLOCK DEVICE ASSEMBLY 1
103 ----- BRACKET, CHAIN BLOCK DEVICE 1
104 ----- SCREW 1
24A 770251 KIT, OUTLET TUBE 1
25A 770252 KIT, BAR COVER, NA & EU 1
26A 770253 KIT, BAR, NA & EU 1
27A 770254 KIT, SAW CHAIN 1
28A 770255 KIT, FRONT HANDLE ASSEMBLY 1
105 ----- SCREW 4
106 ----- HANDLE, FRONT 1
107 ----- SHEATH 1
108A 1760266 BATTERY, 2AH, NA (OPTION) 1
109A 1760263 CHARGER, RAPID, NA (OPTION) 1
Not for Reproduction

Snapper XD Series Specifications

General

Chain Brake	Yes
Engine Displacement	42 cc
Power Source	Gasoline
Bar Length	18 inches
Chain Pitch	0.325 in
Chain Gauge	0.050 inches
