Section

7.2

7-22 A38E Work Platform

Illustrated Parts Breakdown

MOTOR/PUMP ASSEMBLY

057530-000

NOTE: THE PART NUMBER FOR THE

MOTOR ASSEMBLY (ALL ITEMS FROM

2 TO 17) IS 058861-000

ITEM PART NO. DESCRIPTION QTY.

1 058862-000 HYDRAULIC PUMP 1

* 058862-001 SEAL KIT 1

2 058847-000 COUPLING 1

3 ─ OIL SEAL 1

4 ─ PUMP MOUNTING FACE 1

5 ─ CIRCLIP 1

6 ─ BEARING 1

7 ─ CIRCLIP 1

8 ─ CIRCLIP 1

9 ─ COOLING FAN 1

10 ─ COMMUTATOR 1

11 ─ BEARING 1

12 ─ COMMUTATOR COVER 1

13 ─ BRUSH HOUSING SUPPORT 1

14 058863-000 BRUSH 4

15 ─ END HOUSING 1

16 ─ TE

RMINAL BLOCK 1

17 ─ VENT/ INSPECTION CAP 4
