Section

7.2

7-38 A38E Work Platform

Illustrated Parts Breakdown

MASTER/SLAVE CYLINDER ASSEMBLY

MASTER CYLINDER 058734-000

SLAVE CYLINDER 058735-000

NOTE: ITEMS 6 TO 10 INCLUSIVE, 12 & 14

FORM THE SEAL KIT FOR THE A38E

MASTER OR SLAVE CYLINDER. THE

PART NUMBER FOR THIS SEAL KIT IS

058750-000

ITEM PART NO. DESCRIPTION QTY.

1 ─ CYLINDER BODY 1

2 ─ VALVE BLOCK BODY 1

3 058728-000 SINGLE OVERCENTRE VALVE 1

4 ─ END CAP 1

5 ─ ROD AND END PIVOT 1

6 SEE NOTE U-RING ROD SEAL 1

7 SEE NOTE ROD SEAL 1

8 SEE NOTE WIPER 1

9 SE

E NOTE

BACK UP O-RING 1

10 SEE NOTE O-RING 1

11 ─ SPACER 1

12 SEE NOTE PISTON O-RING 1

13 ─ PISTON HEAD 1

14 SEE NOTE PISTON SEAL 1

15 ─ PISTON LOCKOUT 1

16 ─ WASHER 1

17 057048-000 GREASE NIPPLE 2
