Section
7.2
7-14 A38E Work Platform
Illustrated Parts Breakdown
WHEEL HUB ASSEMBLY
057669-000
ITEM PART NO. DESCRIPTION QTY.
1 057665-000 WHEEL HUB 1
2 057664-000 THRUST BEARING 1
3 057662-000 PIVOT BOSS 1
4 057663-000 PIVOT PIN 1
5 057585-000 COVER PLATE 1
6 057584-000 OUTER HUB BEARING 1
7 057583-000 INNER HUB BEARING 1
8 057582-000 STUD 5
9 057661-000 PIVOT BUSHING 30/38 x 30 long 2
