Snorkel A38E - Upper Lift Cylinder Assembly

Section
7.2
7-32 A38E Work Platform
Illustrated Parts Breakdown
UPPER LIFT CYLINDER ASSEMBLY
504505-010
NOTE: ITEMS 6 TO 10 INCLUSIVE, 12 & 14
FORM THE SEAL KIT FOR THE A38E
UPPER LIFT CYLINDER. THE PART
NUMBER FOR THIS SEAL KIT IS
500458-000
ITEM PART NO. DESCRIPTION QTY.
1 ─ CYLINDER BODY 1
2 500397-000 EMERGENCY LOWERING VALUE 1
3 058728-000 SINGLE OVERCENTRE VALVE 1
4 ─ END CAP 1
5 ─ ROD AND END PIVOT 1
6 SEE NOTE U-RING ROD SEAL 1
7 SEE NOTE ROD SEAL 1
8 SEE NOTE WIPER 1
9 SEE NOTE BACK UP
O-RING 1
10 SEE NOTE O-RING 1
11 ─ SP
ACER 1
12 SEE NOTE PISTON O-RING 1
13 ─ PISTON HEAD 1
14 057122-000 PISTON SEAL 1
15 ─ PISTON LOCKNUT 1
16 ─ WASHER 1
17 501964-001 GREASE NIPPLE 2
