Snorkel A38E - Page 48

Maintenance
Section
4-16 A38E Work Platform
4.11
Figure 4-13: Electric Motor Assembly
1. Pump
2. Bearing
3. Pulley End Cover
4. Pulley End Bearing
5. Armature
6. Commutator
7. Bearing
8. Stator Housing
9. Brush Housing Support
10. Commutator End Cover
11. Inspection Cover
12. Brush Holders
13. Brush Retaining Spring
14. Brushes
15. Retaining Bolt
16. Coupling
10
9
8
7
6
5
9
12
1
3
11
10
2
4
13
14
15
16
