6-2 A38E Work Platform
6.0
A38E CE Electric Kit Parts
Circuit Diagram: 512819- 002
DESCRIPTION PART No.
PLATFORM CONTROL BOX 513433-002
Enclosure(cut-out) 512936-002 -
Joys
ck 510471-000 1
Matrix Board 510472-000 1
Overload I/F Board
13468-01
1
Alarm 502588-000 1
Twist& Release E/stop c/w 1 N/C contact block 510524-000 1
Black Flush Push Bu
on c/w 1 N/O contact block 510542-000 2
Toggle Switch, on-(on) IP65 510521-000 6
Boot 514132-000 6
Red LED 512934-000 2
Green LED 512935-000 5
Pl
a
orm Control Box Overlay 512937-002 1
9-way Chassis Socket 513949-000 1
6-way Panel Plug 510154-000 1
9-way Panel Plug 510156-000 1
12-way Panel Plug 510157-000 2
4-way Panel Plug 512366-000 2
3-way Panel Plug 510155-000 1
2-way Panel Plug 512816-000 1
Mate-N-Lock Socket Contact 510145-000 42
9-way Bulkhead Connector 512938-000 1
DIN Rail 512368-000 0.4
GROUND CONTROL PANEL 513434-000
Ground Control Panel 512939-001 1
Ground Control Panel Overlay 512940-000 1
Ezcal Display 3087803 1
Twist& Release E/stop c/w 1 N/C contact block 510524-000 1
3 posn. Stayput Key Switch (key removeable only in
off posi on) c/w/2 N/O contact blocks 512543-000 1
Analogue Rocker 514131-000 1
Deadman Toggle Switch, on-(on) IP65 510521-000 4
Boot 514132-000 4
19-Way Cable Clamp Socket 513951-000 1
4-way Panel Plug 512366-000 1
Mate-N-Lock Socket Contact 510145-000 4
3 amp diode. 510150-000 2
External Components
12v Solenoid coil 505555-016 14
Alarm 502588-000 1
Alarm bracket 512684-000 1
Fuse 300Amp 067387-022 1
Fuse holder 501877-000 1
Contactor 513550-000 1
GP400 512941-000 1
SEM600 512942-000 1
P600 512943-000 1
Load Cell
513160-000
1
Load Cell Cable Harness
513161-000
1
Trac
on motors 512944-000 2
Eleva
on Switch 058864-000 1
Horn 501868-001 1
Ferrite 510437-000 5
Cable Assemblies
A38E Wire Harness PG Tr
ionics 513539-000 1
A38E Valve Cable 513540-001 1
A38E Addi
onal Cable Kit 513541-000 1
A38E Power Cable Kit 513542-000 1
QTY.
